| SIZE(MM) | H(MM) | H1(MM) | C(MM) | D(MM) | L(MM) | L1(MM) | E(MM) | S.W.L.(LBS) |
| 3.5 | 36 | 29 | 5 | 3.5 | 31.5 | 24 | 11 | 200 |
| 4 | 40 | 32 | 5.5 | 4 | 35.5 | 27.5 | 12.5 | 250 |
| 5 | 48 | 38 | 6.5 | 5 | 40 | 30 | 16 | 330 |
| 6 | 56 | 44 | 7.5 | 6 | 47 | 35 | 19 | 550 |
| 8 | 73 | 57 | 10.5 | 8 | 56 | 40 | 24 | 1210 |
| 10 | 87 | 67 | 12 | 10 | 66 | 46 | 29 | 1320 |
| 12 | 104 | 80 | 15 | 12 | 75 | 51 | 33 | 2425 |
