| SIZE(MM) | D(MM) | L(MM) | B.L.(LBS) |
| 3X10 | 3 | 10 | 650 |
| 3X15 | 3 | 15 | 650 |
| 3X20 | 3 | 20 | 650 |
| 3X25 | 3 | 25 | 650 |
| 3X30 | 3 | 30 | 650 |
| 3X35 | 3 | 35 | 650 |
| 3X40 | 3 | 40 | 650 |
| 4X20 | 4 | 20 | 1000 |
| 4X25 | 4 | 25 | 1000 |
| 4X30 | 4 | 30 | 1000 |
| 4X35 | 4 | 35 | 1000 |
| 4X40 | 4 | 40 | 1000 |
| 5X20 | 5 | 20 | 2000 |
| 5X25 | 5 | 25 | 2000 |
| 5X30 | 5 | 30 | 2000 |
| 5X35 | 5 | 35 | 2000 |
| 5X40 | 5 | 40 | 2000 |
| 5X45 | 5 | 45 | 2000 |
| 5X50 | 5 | 50 | 2000 |
| 5X60 | 5 | 60 | 2000 |
| 5X65 | 5 | 65 | 2000 |
| 6X25 | 6 | 25 | 2700 |
| 6X30 | 6 | 30 | 2700 |
| 6X35 | 6 | 35 | 2700 |
| 6X40 | 6 | 40 | 2700 |
| 6X45 | 6 | 45 | 2700 |
| 6X50 | 6 | 50 | 2700 |
| 6X55 | 6 | 55 | 2700 |
| 6X60 | 6 | 60 | 2700 |
| 6X80 | 6 | 80 | 2700 |
| 6X90 | 6 | 90 | 2700 |
| 7X40 | 7 | 40 | 3200 |
| 7X45 | 7 | 45 | 3200 |
| 7X50 | 7 | 50 | 3200 |
| 7X55 | 7 | 55 | 3200 |
| 7X60 | 7 | 60 | 3200 |
| 7X65 | 7 | 65 | 3200 |
| 8X30 | 8 | 30 | 5000 |
| 8X35 | 8 | 35 | 5000 |
| 8X40 | 8 | 40 | 5000 |
| 8X45 | 8 | 45 | 5000 |
| 8X50 | 8 | 50 | 5000 |
| 8X55 | 8 | 55 | 5000 |
| 8X60 | 8 | 60 | 5000 |
| 8X65 | 8 | 65 | 5000 |
| 8X70 | 8 | 70 | 5000 |
| 8X75 | 8 | 75 | 5000 |
| 8X80 | 8 | 80 | 5000 |
| 8X90 | 8 | 90 | 5000 |
| 8X100 | 8 | 100 | 5000 |
| 9X30 | 9 | 30 | 6200 |
| 9X50 | 9 | 50 | 6200 |
| 9X60 | 9 | 60 | 6200 |
| 9X65 | 9 | 65 | 6200 |
| 9X70 | 9 | 70 | 6200 |
| 9X80 | 9 | 80 | 6200 |
| 9X90 | 9 | 90 | 6200 |
| 10X40 | 10 | 40 | 8500 |
| 10X50 | 10 | 50 | 8500 |
| 10X55 | 10 | 55 | 8500 |
| 10X60 | 10 | 60 | 8500 |
| 10X65 | 10 | 65 | 8500 |
| 10X70 | 10 | 70 | 8500 |
| 10X75 | 10 | 75 | 8500 |
| 10X80 | 10 | 80 | 8500 |
| 10X90 | 10 | 90 | 8500 |
| 10X100 | 10 | 100 | 8500 |
| 10X120 | 10 | 120 | 8500 |
| 10X140 | 10 | 140 | 8500 |
| 12X60 | 12 | 60 | 10000 |
| 12X65 | 12 | 65 | 10000 |
| 12X70 | 12 | 70 | 10000 |
| 12X75 | 12 | 75 | 10000 |
| 12X80 | 12 | 80 | 10000 |
| 12X90 | 12 | 90 | 10000 |
| 12X100 | 12 | 100 | 10000 |
| 12X110 | 12 | 110 | 10000 |
| 12X120 | 12 | 120 | 10000 |
| 13X40 | 13 | 40 | 11500 |
| 13X55 | 13 | 55 | 11500 |
| 13X60 | 13 | 60 | 11500 |
| 13X70 | 13 | 70 | 11500 |
| 13X80 | 13 | 80 | 11500 |
| 13X90 | 13 | 90 | 11500 |
| 13X100 | 13 | 100 | 11500 |
| 13X120 | 13 | 120 | 11500 |
| 13X130 | 13 | 130 | 11500 |
| 13X140 | 13 | 140 | 11500 |
| 13X150 | 13 | 150 | 11500 |
| 13X160 | 13 | 160 | 11500 |
